Application:
1 Heat/1 Cool Conventional Systems and Heat Pumps with No Auxiliary Heat
Features
Backlit display is easy to read
Displays ambient (measured) temperature at all times
One-touch access to setpoint temperature
Built-in compressor protection
Application:
Single-Stage (Heat/Cool)
Heat Pump
Stages:
1 Heat/1 Cool
Programmability:
Non-Programmable
Power Method:
Hardwired
Battery
User Interface:
Push Button
Mount:
Vertical
Options:
Fan Control
Changeover:
Manual
Temperature Range (F):
40°F – 90°F (Heating)
50°F – 99°F (Cooling)
Operating Humidity:
5 to 90% RH, non-condensing
Voltage:
Low voltage
24v
750mV
Amperage:
0.02-1
Wiring:
R, RC, C, W, Y, G, O, B
Color:
Premier White
Height:
4-11/16″
Width:
2-7/8″
Depth (Inches):
1-1/8″
1 Heat/1 Cool Conventional Systems and Heat Pumps with No Auxiliary Heat
Features
Backlit display is easy to read
Displays ambient (measured) temperature at all times
One-touch access to setpoint temperature
Built-in compressor protection
Application:
Single-Stage (Heat/Cool)
Heat Pump
Stages:
1 Heat/1 Cool
Programmability:
Non-Programmable
Power Method:
Hardwired
Battery
User Interface:
Push Button
Mount:
Vertical
Options:
Fan Control
Changeover:
Manual
Temperature Range (F):
40°F – 90°F (Heating)
50°F – 99°F (Cooling)
Operating Humidity:
5 to 90% RH, non-condensing
Voltage:
Low voltage
24v
750mV
Amperage:
0.02-1
Wiring:
R, RC, C, W, Y, G, O, B
Color:
Premier White
Height:
4-11/16″
Width:
2-7/8″
Depth (Inches):
1-1/8″
