SDS1152 Sta-Rite Direct Replacement Spa Motor 1.5-.19 HP

Product Description

SDS1152 1.5-.19 HP
Features:Open Construction, Rigid Base, Sealed ball Bearing, Threaaded Shaft, Thru Bolt Mounting, 50C Ambient, 1.0 Service Factor, Energy Efficient, Auto Protector, 2 Speed(Capacitor start low speed, PSC high Speed), Rotation(CCW Pump End)

Sta-Rite Direct Replacement Spa Motor

Replacement motor for dimensions One, Hydroquip, GPM Industries, Hawkeye, Marquis and Master Spas

Application: Replacement Spa and Hot Tub Only
Not for pool filtration in California or New York

• 1.5-.19 HP
• 3450/1725 RPM
• 230 VOLTS
• 7.2/2.4 AMPS
• 56Z FRAME
• INSULATION CLASS F
  NOTE:When crossing to an original equipment A.O. Smith Motor, use the Quick Cross Reference table. Find the amps and model number of the OEM motor on the motor nameplate. Fidn the equivalent amps and model number on the Quick Reference table below. The replacement is the stock number listed in the “Use” column. The horsepower and service factor may not be the same, but the motors are the same.
  Name plate Model number: K48M2A4

Cross Reference: 5KCR39UN6113X C1316 MC1316
