Like the MU type, the rotating eye grip has a triple weave construction and is color-coded for ease of identification. The steel forged revolving head is ideal for connecting to Slingco swivels. Warning: The Slingco rotating eye does not revolve under load and does not replace the use of a line swivel. Made of galvanized steel.
Features And Benefits
- Steel forged revolving head ideal for connecting to Slingco swivel
- Triple weave construction
- Used for heavy-duty pulling
- Suitable for bare or insulated cable, conductor or wire
- Colour coded for easy identification
| Range (mm) | Lattice Length (mm) | Approx. Break Load (kg) | Colour Code | Slingco Part No. |
|---|---|---|---|---|
| 6 – 12 | 787 | 3,170 | Dark Green | ZCS2177 |
| 12 – 19 | 1,143 | 4,760 | Brown | ZCS2178 |
| 19 – 25 | 1,092 | 6,395 | Light Blue | ZCS2179 |
| 25 – 32 | 1,651 | 11,340 | Gold | ZCS2180 |
| 32 – 38 | 1,499 | 14,065 | Black | ZCS2181 |
| 38 – 44 | 2,083 | 14,065 | Red | ZCS2182 |
| 44 – 57 | 2,083 | 19,510 | Dark blue | ZCS2183 |
| 51 – 63 | 1,829 | 19,510 | Yellow | ZCS2779 |
| 63 – 76 | 1,829 | 19,510 | Orange | ZCS2780 |
| 76 – 89 | 1,880 | 19,510 | Aluminum | ZCS2781 |
| 89 – 102 | 1,930 | 19,510 | Light Green | ZCS2782 |
A note about dimensions and tolerances
