5 TERM RNGLS SML CLS PLT 5TH TERM 9 OCLOCK POS 9-16 IN BRL LCK WITH BRKT PROV LVR BYPS
150
| UPC | 784572256378 |
|---|---|
| UNSPSC | 39121102 |
| Country of Origin | USA |
| Amperage Rating: | 125 Continuous Ampere |
| Size: | 4.844L x 10W x 18.5H |
| Type: | Ringless Meter Socket |
| Voltage Rating: | 600 VAC |
| Amperage Rating: | 125 Continuous Ampere |
| Barrel Lock Provision: | 9/16 Inch Knockout and Angle Bracket for Barrel Lock Provision |
| Bypass Type: | Lever Bypass |
| Cable Entry: | Overhead |
| Cutout Size: | No Main Breaker |
| Enclosure: | G90 Galvanized Steel with Powder Coat Finish |
| Equipment Ground: | Ground Lug |
| Frequency Rating: | 60 Hz |
| Hub Opening: | Small Hub Opening |
| Insulation: | Glass Polyester |
| Jaw Quantity: | 5 Terminal |
| Line Side Wire Range: | 6 – 2/0 AWG |
| Load Side Wire Range: | 6 – 2/0 AWG |
| Mounting: | Surface Mount |
| Number of Meter Positions: | 1 Position |
| Phase: | 1 |
| Size: | 4.844L x 10W x 18.5H |
| Standard: | UL Listed;Type 3R |
| Terminal: | Lay in |
| Type: | Ringless Meter Socket |
| Voltage Rating: | 600 VAC |
