4 TERM RNGLS LRG CLS PLT LVR BYPS SIDE BUSSED 250kcmil MAX
150
| UPC | 784572320697 |
|---|---|
| UNSPSC | 39121102 |
| Country of Origin | USA |
| Amperage Rating: | 320 A |
| Size: | 4.844L x 15W x 31.5H |
| Type: | Ringless Meter Socket |
| Voltage Rating: | 600 VAC |
| Amperage Rating: | 320 A |
| Bypass Type: | Lever Bypass |
| Cable Entry: | Overhead and Underground and Side Wireway |
| Cutout Size: | No Main Breaker |
| Enclosure: | G90 Galvanized Steel with Powder Coat Finish |
| Equipment Ground: | Ground Lug |
| Frequency Rating: | 60 Hz |
| Hub Opening: | Large Closing Plate |
| Insulation: | Glass Polyester |
| Jaw Quantity: | 4 Terminal |
| Line Side Wire Range: | 6 AWG – 350 kcmil |
| Mounting: | Surface Mount |
| Number of Meter Positions: | 1 Position |
| Phase: | 1 |
| Size: | 4.844L x 15W x 31.5H |
| Standard: | UL Listed;Type 3R |
| Terminal: | 3/8 Inch Stud |
| Type: | Ringless Meter Socket |
| Voltage Rating: | 600 VAC |
