4 TERM RNGTP PLAIN TOP SGL PED DIR BURY
150
| UPC | 784572258402 |
|---|---|
| UNSPSC | 39121102 |
| Country of Origin | USA |
| Amperage Rating: | 125 Continuous Ampere |
| Size: | 5.313L x 8.688W x 70.25H |
| Type: | Ring Type Meter Socket |
| Voltage Rating: | 240 VAC |
| Amperage Rating: | 125 Continuous Ampere |
| Bypass Type: | No Bypass |
| Cable Entry: | Underground |
| Cutout Size: | Breaker Provision |
| Enclosure: | G90 Galvanized Steel with Powder Coat Finish |
| Equipment Ground: | 2 Barrel Ground Lug and Ground Bar |
| Frequency Rating: | 60 Hz |
| Hub Opening: | Plain Top |
| Insulation: | Glass Polyester |
| Jaw Quantity: | 4 Terminal |
| Line Side Wire Range: | 6 AWG – 350 kcmil |
| Mounting: | Pedestal |
| Number Branch Circuits: | 6 |
| Number of Meter Positions: | Single Power Head |
| Phase: | 1 |
| Size: | 5.313L x 8.688W x 70.25H |
| Standard: | UL Listed;Type 3R |
| Terminal: | Double Mechanical |
| Type: | Ring Type Meter Socket |
| Voltage Rating: | 240 VAC |
